Calpeda 1-MXH VMT, VTT

Constant pressure station with one pump with Variomat frequency converter. With a ball valve, a non-return valve at the suction, a ball valve and a pressure gauge on the discharge, suitable for the installation of an 8 liter pressure vessel. See more

on demand check availability

from 2,272.82 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Pressure booster sets with frequency converter - horizontal
Product No.:
MAS000375

Product variants

CALPEDA

Calpeda 1-MXH VMT, VTT

  • Technical Specifications
  • Product No.
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Product description

Devices

  • The frequency converter is installed directly on the discharge pipe and is cooled by water
  • Only two parameters at startup
  • Maximum motor current
  • Work pressure

Display options

  • System pressure
  • Operating frequency
  • Rated current
  • Alarm. reporting

Traffic

  • According to flow requirements, it provides the necessary amount of water at a constant pressure

Use

  • For pumping water from a well or borehole
  • To increase the pressure of the distribution network (follow local regulations and consult with the owner of the water supply)

Engine

  • 2-pole asynchronous motors, 50 Hz, n = 2900 1/min
  • Three-phase 230/400V ± 10%
  • Insulation class F
  • Degree of protection IP 54
  • Constructed in accordance with: IEC 60034
  • Other voltages and frequencies on request
