Calpeda 4 SDF - 400V submersible borehole pumps with radial floating impellers

Drinking water certificate

previous next
Calpeda 4 SDF - 400V submersible borehole pumps with radial floating impellers

Submersible borehole pumps for 4” and 6" FLOW 0.15 / 21 mc/h HEAD 6.6 / 305 m  POWER 0.37 / 10 kW

See more

Technical Specifications

Maximum flow [l/min]
40 - 135
Maximum head [m]
43 - 339
Input voltage [V]
3x400
Power output - P2 [kW]
0.55 - 4

Show all Tech Specs

available in 5 working days >10 pcs

from 469.03 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Submersible borehole pumps
Product No.:
MAS000264

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda 4 SDF 16/14 0,55kW 400V submersible pump with Franklin motor

Product No.: ZB00001744 Sale group: CECK EAN: 8596455030645

available in 5 working days
1 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 1 pcs

546.32 €

Maximum flow [l/min]
40
Maximum head [m]
84.30
Input voltage [V]
3x400
Power output - P2 [kW]
0.55
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
1.60
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Calpeda 4 SDF 16/27 1,1kW 400V submersible pump with Franklin motor

Product No.: ZB00001746 Sale group: CECK EAN: 8596455030652

available in 5 working days
3 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 3 pcs

681.53 €

Maximum flow [l/min]
40
Maximum head [m]
163
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
2.80
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Calpeda 4 SDF 36/11 0,75kW 400V submersible pump with Franklin motor

Product No.: ZB00001755 Sale group: CECK EAN: 8596455030737

available in 5 working days
4 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 4 pcs

495.60 €

Maximum flow [l/min]
80
Maximum head [m]
64
Input voltage [V]
3x400
Power output - P2 [kW]
0.75
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
2
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Calpeda 4 SDF 36/58 4,0kW 400V submersible pump with Franklin motor

Product No.: ZB00024396 Sale group: CECK EAN: 8596455033110

available in 5 working days
1 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 1 pcs

1,477.03 €

Not sellable online

Maximum flow [l/min]
80
Maximum head [m]
339
Input voltage [V]
3x400
Power output - P2 [kW]
4
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
9.90
Maximum liquid temperature [°C]
30
Cable length [m]
2.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Calpeda 4 SDF 46/10 0,75kW 400V submersible pump with Franklin motor

Product No.: ZB00001760 Sale group: CECK EAN: 8596455030782

available in 5 working days
1 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 1 pcs

501.15 €

Maximum flow [l/min]
100
Maximum head [m]
59
Input voltage [V]
3x400
Power output - P2 [kW]
0.75
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
2
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Calpeda 4 SDF 46/31 2,2kW 400V submersible pump with Franklin motor

Product No.: ZB00001763 Sale group: CECK EAN: 8596455030812

available in 5 working days
1 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 1 pcs

893.99 €

Not sellable online

Maximum flow [l/min]
100
Maximum head [m]
183
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
5.50
Maximum liquid temperature [°C]
30
Cable length [m]
2.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Calpeda 4 SDF 54/07 0,75kW 400V submersible pump with Franklin motor

Product No.: ZB00014219 Sale group: CECK EAN: 8596455031963

available in 5 working days
1 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days 1 pcs

469.03 €

Maximum flow [l/min]
135
Maximum head [m]
43
Input voltage [V]
3x400
Power output - P2 [kW]
0.75
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
2
Maximum liquid temperature [°C]
30
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal

Product description

Construction

Submersible borehole pumps for 4” wells (DN 100 mm), and 6” (DN 150 mm), with external jacket in stainless steel AISI 304 and stages in Noryl.

Impellers:
radial floating impellers: 4SDP.
Radial impellers: 6SDN 12, 16, 21.
Mixed flow impellers: 6SD 18, 19, 20.
Connection: screwed connection ISO 228.
Delivery casing with built-in non-return valve.

Applications

- For water supply.
- For civil and industrial applications.
- For fire fighting applications.
- For irrigation.

Instructions

Technical Specifications

Maximum flow [l/min]
40 - 135
Maximum head [m]
43 - 339
Input voltage [V]
3x400
Power output - P2 [kW]
0.55 - 4
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Maximum current [A]
1.60 - 9.90
Maximum liquid temperature [°C]
30
Cable length [m]
1.50 - 2.50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
