Calpeda E-MXAM 403-PCD 0,55kW 230V

Pressurized system with integrated pressure control
(Multi-stage Self-Priming Pump) See more

Technical Specifications

Maximum flow [l/min]
100
Maximum head [m]
33.80
Input voltage [V]
230
Power output - P2 [kW]
0.55

Show all Tech Specs

on demand check availability

470.22 € VAT included

On demand

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Horizontal surface pumps
Product No.:
ZB00061605
Sale group:
CECK
EAN:
8030485998471
Manuf. No.:
T663A10310D0

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda E-MXAM 403-PCD 0,55kW 230V

Product No.: ZB00061605 Sale group: CECK EAN: 8030485998471 Manuf. No.: T663A10310D0

on demand
check availability
Product availability
  • central warehouse 0 pcs

470.22 €

Check availability

Maximum flow [l/min]
100
Maximum head [m]
33.80
Input voltage [V]
230
Power output - P2 [kW]
0.55
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
3.80
Cable length [m]
1.50
Protection [IP]
X4
Automatic thermal protection
YES
Dry run protection
YES
Off switch
YES
Speed ​​control
YES
Capacitor
integrated
Pump design
horizontal
Impeller material
noryl
Construction
multi-stage
You are viewing this variant

Calpeda E-MXAM 404-PCD 0,75kW 230V

Product No.: ZB00061606 Sale group: CECK EAN: 8030485238898 Manuf. No.: T663A10410D0

on demand
check availability
Product availability
  • central warehouse 0 pcs

512.94 €

Check availability

Maximum flow [l/min]
108.30
Maximum head [m]
44.50
Input voltage [V]
230
Power output - P2 [kW]
0.75
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
4.80
Cable length [m]
1.50
Protection [IP]
X4
Automatic thermal protection
YES
Dry run protection
YES
Off switch
YES
Speed ​​control
YES
Capacitor
integrated
Pump design
horizontal
Impeller material
noryl
Construction
multi-stage

Product description

Construction

Pressurized system with integrated pressure control.
Easy to install and Compact plug and play booster set.
Brand new asynchronous single-phase motor.

Equipped with pressure transducer, non-return valve, controlled starting current and temperature.

Equipped with a programmable software and, thanks to the analogic pressure sensor, the product allows to set the re-start pressure.
An ideal solution which allows to reduce or remove the need of a expansion tank.

Features

  • high efficiency asynchronous single-phase motor
  • capacitor not stressed in voltage
  • uniform and lower motor temperature
  • motor power control
  • programmable re-start pressure
  • no hydraulic losses due to the measuring devices
  • voltage and current control
  • monitoring of maximum starting current
  • elimination of water hammer

Protections

  • dry-run protection
  • air detection in the pump and in the filling cycle
  • overload control and overheating motor control
  • pump blockage
  • overcurrent protection
  • power supply control
  • system leakage control
  • high flow rate and piping failure detection

Instructions

Technical Specifications

Maximum flow [l/min]
100
Maximum head [m]
33.80
Input voltage [V]
230
Power output - P2 [kW]
0.55
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
6
Drinking water certificate
NO
Maximum current [A]
3.80
Cable length [m]
1.50
Protection [IP]
X4
Automatic thermal protection
YES
Dry run protection
YES
Off switch
YES
Speed ​​control
YES
Capacitor
integrated
Pump design
horizontal
Impeller material
noryl
Construction
multi-stage
