Calpeda NGX 6/18A 1,5kW 230/400V 2900rpm self-priming pump

Close-coupled self-priming shallow-well pump with built-in ejector. See more

Technical Specifications

Maximum flow [l/min]
100
Maximum head [m]
58
Input voltage [V]
3x400
Power output - P2 [kW]
1.50

Show all Tech Specs

on demand check availability

605.99 € VAT included

On demand

Delivery accross EU within 3-7 business days %

Brand:
CALPEDA
Category:
Horizontal surface pumps
Product No.:
ZB00025746
Sale group:
CECK
EAN:
8030485896333
Manuf. No.:
72A50044200

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Calpeda NGX 6/18A 1,5kW 230/400V 2900rpm self-priming pump

Product No.: ZB00025746 Sale group: CECK EAN: 8030485896333 Manuf. No.: 72A50044200

on demand
check availability
Product availability
  • central warehouse 0 pcs

605.99 €

Check availability

Maximum flow [l/min]
100
Maximum head [m]
58
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
9
Drinking water certificate
YES
Maximum current [A]
4.30
Maximum liquid temperature [°C]
35
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
horizontal
Impeller material
brass
Construction
ejector
You are viewing this variant

Calpeda NGX 6/22/A 1,5kW 230/400V 2900rpm self-priming pump

Product No.: ZB00001701 Sale group: CECK EAN: 8030485909767 Manuf. No.: 72A50045200

on demand
check availability
Product availability
  • central warehouse 0 pcs

605.99 €

Check availability

Maximum flow [l/min]
140
Maximum head [m]
46.50
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
9
Drinking water certificate
YES
Maximum current [A]
4.30
Maximum liquid temperature [°C]
35
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
horizontal
Impeller material
brass
Construction
ejector

Product description

Construction

Close-coupled self-priming shallow-well pump with built-in ejector.
A high-quality pump for domestic water supply. Designed with environmental considerations, featuring a stainless steel casing, brass alloy impeller with minimal use of plastic materials.

Applications

- For drawing water out of a well.
- For lifting water containing air or other gases.
- For increasing water pressure from flooded suction applications.
- As pressure boosting pump for central water systems with low pressure (follow local specifications if increasing network pressure).
- For garden use.
- For washing with a jet of water.

Instructions

Technical Specifications

Maximum flow [l/min]
100
Maximum head [m]
58
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Suction port ["]
5/4
Delivery port ["]
1
Maximum suction lift [m]
9
Drinking water certificate
YES
Maximum current [A]
4.30
Maximum liquid temperature [°C]
35
Protection [IP]
54
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Pump design
horizontal
Impeller material
brass
Construction
ejector
