GRUNDFOS MAGNA1 D stainless steel threaded circulator pump

previous next
GRUNDFOS MAGNA1 D stainless steel threaded circulator pump

Double the pump performance or enjoy reduced downtime in service by having redundancy from the twin pump (manual change over). The basic product which can be operated from an intuitive user interface See more

Technical Specifications

Maximum flow [l/min]
116 - 166
Maximum head [m]
4 - 10
Input voltage [V]
230
Suction port ["]
2

Show all Tech Specs

on demand check availability

from 1,140.70 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Heating pumps
Product No.:
MAS000473

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA1 D 32-40 180 230V PN6/10

Product No.: ZB00030097 Sale group: CEGBA EAN: 5712608942112 Manuf. No.: 99221238

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,140.70 €

Check availability

Maximum flow [l/min]
116
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.59
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 D 32-60 180 230V PN6/10

Product No.: ZB00030099 Sale group: CEGBA EAN: 5712608942129 Manuf. No.: 99221239

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,333.70 €

Check availability

Maximum flow [l/min]
141
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.90
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 D 32-80 180 230V PN6/10

Product No.: ZB00030101 Sale group: CEGBA EAN: 5712608942136 Manuf. No.: 99221240

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,389.60 €

Check availability

Maximum flow [l/min]
158
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.22
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 D 32-100 180 230V PN6/10

Product No.: ZB00030094 Sale group: CEGBA EAN: 5712608942143 Manuf. No.: 99221241

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,525.36 €

Check availability

Maximum flow [l/min]
166
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1,41
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Product description

MAGNA1 D is a twin head circulator pump designed for simpler jobs

The MAGNA1 D circulator pump is characterised by its two pump heads which share the same pump housing. The pump heads are connected wirelessly, and one acts as a redundant back-up to the other. So, if one becomes unavailable, the other will take over – providing you with peace-of-mind and guaranteeing you a continuous supply. MAGNA1 D also offers a fault relay output and a digital start/stop input, enabling integration with simple building management systems.

Wireless twin pump functionality

MAGNA1 D offers wireless, alternating twin pump functionality for redundancy and maximum uptime.

Double the reliability

One pump head is redundant and takes over if the other becomes unavailable.

Double the power

Both MAGNA1 D pump heads can handle the full flow individually, ensuring a security of supply.

Double the potential

The pump heads communicate wirelessly and can reach flow levels of up to 70m3/h.

Instructions

Technical Specifications

Maximum flow [l/min]
116 - 166
Maximum head [m]
4 - 10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.59 - 1.41
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180
