GRUNDFOS MAGNA1 N stainless steel threaded circulator pump

MAGNA1 N is the stainless steel variant for applications where the media requires this (e.g. domestic hot water). With MAGNA1, the job is done in an intuitive and efficient way See more

Technical Specifications

Maximum flow [l/min]
100 - 166.67
Maximum head [m]
4 - 12
Input voltage [V]
230
Suction port ["]
6/4, 2

Show all Tech Specs

in stock 2 pcs

from 781.58 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Hot water recirculation pumps
Product No.:
MAS000471

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA1 25-40 N 180 230V PN6/10

Product No.: ZB00014754 Sale group: CEGBA EAN: 5712608941962 Manuf. No.: 99221223

on demand
check availability
Product availability
  • central warehouse 0 pcs

781.58 €

Check availability

Maximum flow [l/min]
100
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.45
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-60 N 180 230V PN10

Product No.: ZB00002409 Sale group: CEGBA EAN: 5712608941979 Manuf. No.: 99221224

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

929.98 €

Maximum flow [l/min]
116.67
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0.74
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-80 N 180 230V PN6/10

Product No.: ZB00002369 Sale group: CEGBA EAN: 5712608941986 Manuf. No.: 99221225

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,059.09 €

Check availability

Maximum flow [l/min]
133.33
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1.03
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-100 N 180 230V PN6/10

Product No.: ZB00002370 Sale group: CEGBA EAN: 5712608941993 Manuf. No.: 99221226

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,174.22 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1.42
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-120 N 180 230V PN6/10

Product No.: ZB00030073 Sale group: CEGBA EAN: 5712608942006 Manuf. No.: 99221227

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,320.66 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1.51
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-40 N 180 230V PN6/10

Product No.: ZB00002371 Sale group: CEGBA EAN: 5712608942266 Manuf. No.: 99221253

on demand
check availability
Product availability
  • central warehouse 0 pcs

962.62 €

Check availability

Maximum flow [l/min]
125
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.59
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-60 N 180 230V PN6/10

Product No.: ZB00012220 Sale group: CEGBA EAN: 5712608942273 Manuf. No.: 99221254

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

1,124.34 €

Maximum flow [l/min]
150
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0.90
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-80 N 180 230V PN6/10

Product No.: ZB00002372 Sale group: CEGBA EAN: 5712608942280 Manuf. No.: 99221255

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,174.25 €

Check availability

Maximum flow [l/min]
166.67
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.22
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-100 N 180 230V PN6/10

Product No.: ZB00030074 Sale group: CEGBA EAN: 5712608942297 Manuf. No.: 99221256

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,288.05 €

Check availability

Maximum flow [l/min]
166.67
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.41
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-120 N 180 1x230V PN10

Product No.: ZB00050244 Sale group: CEGBA EAN: 5712608942563 Manuf. No.: 99221283

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,394.53 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1.51
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Product description

Instructions

Technical Specifications

Maximum flow [l/min]
100 - 166.67
Maximum head [m]
4 - 12
Input voltage [V]
230
Suction port ["]
6/4, 2
Delivery port ["]
6/4, 2
Maximum current [A]
0.45 - 1.51
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180
