GRUNDFOS MAGNA1 threaded circulator pump

The simple option for a job well done. The product has an intuitive user interface, which is especially fit for replacement of older circulators. The ideal choice for basic functionality needs See more

Technical Specifications

Maximum flow [l/min]
100 - 166.67
Maximum head [m]
4 - 12
Input voltage [V]
230
Suction port ["]
6/4, 2

Show all Tech Specs

in stock >50 pcs

from 459.47 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Heating pumps
Product No.:
MAS000469

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA1 25-40 180 230V PN10

Product No.: ZB00002329 Sale group: CEGK1 EAN: 5712608941894 Manuf. No.: 99221216

in stock
10 pcs
Product availability
  • central warehouse 10 pcs

459.47 €

Maximum flow [l/min]
100
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0,45
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-60 180 230V PN10

Product No.: ZB00002330 Sale group: CEGK1 EAN: 5712608941900 Manuf. No.: 99221217

in stock
8 pcs
Product availability
  • central warehouse 8 pcs

545.99 €

Maximum flow [l/min]
116,67
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
0,74
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-80 180 230V PN10

Product No.: ZB00002326 Sale group: CEGK1 EAN: 5712608941863 Manuf. No.: 99221213

in stock
8 pcs
Product availability
  • central warehouse 8 pcs

621.61 €

Maximum flow [l/min]
133,33
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1,03
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-100 180 230V PN10

Product No.: ZB00002327 Sale group: CEGK1 EAN: 5712608941870 Manuf. No.: 99221214

on demand
check availability
Product availability
  • central warehouse 0 pcs

686.95 €

Check availability

Maximum flow [l/min]
150
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1,42
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 25-120 180 230V PN10

Product No.: ZB00002328 Sale group: CEGK1 EAN: 5712608941887 Manuf. No.: 99221215

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

774.12 €

Maximum flow [l/min]
150
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
6/4
Delivery port ["]
6/4
Maximum current [A]
1,51
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-40 180 230V PN10

Product No.: ZB00002331 Sale group: CEGK1 EAN: 5712608942068 Manuf. No.: 99221233

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

565.36 €

Maximum flow [l/min]
125
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0,59
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-60 180 230V PN10

Product No.: ZB00002332 Sale group: CEGK1 EAN: 5712608942075 Manuf. No.: 99221234

in stock
10 pcs
Product availability
  • central warehouse 10 pcs

659.74 €

Maximum flow [l/min]
150
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
0,90
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-80 180 230V PN10

Product No.: ZB00002333 Sale group: CEGK1 EAN: 5712608942082 Manuf. No.: 99221235

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

686.97 €

Maximum flow [l/min]
166,67
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1,22
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-100 180 230V PN6/10

Product No.: ZB00002334 Sale group: CEGK1 EAN: 5712608942099 Manuf. No.: 99221236

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

755.33 €

Maximum flow [l/min]
166,67
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1,41
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Grundfos MAGNA1 32-120 180 1x230V PN10

Product No.: ZB00047587 Sale group: CEGK1 EAN: 5712608942549 Manuf. No.: 99221281

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

816.44 €

Maximum flow [l/min]
150
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
2
Delivery port ["]
2
Maximum current [A]
1,51
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180

Product description

MAGNA1 is a cost-efficient circulator pump that gets the simpler jobs done

MAGNA1 is a canned rotor circulator pump, which is a cost-efficient solution for any jobs that do not require highly-advanced intelligent communication and control. The pump offers a fault relay output and a digital start/stop input, enabling integration with simple building management systems. MAGNA1 is designed to circulate liquids in a wide range of applications including heating, cooling, and domestic hot water systems, to name a few. Based on the tried and tested MAGNA technology of its predecessors, it is a reliable, cost-efficient and user-friendly circulator.

Best-in-class efficiency

MAGNA1 offers best-in-class efficiency, resulting in significant energy savings.

Easy operation

MAGNA1 is characterised by simplicity and can be commissioned just by the push of a button.

Simple connectivity

Its fault relay output and digital start/stop input allows for simple connectivity to external monitoring systems.

Tested to the limit

MAGNA1 is built on tried and tested MAGNA technology, which is your guarantee for a long-lasting pump.

Instructions

Technical Specifications

Maximum flow [l/min]
100 - 166.67
Maximum head [m]
4 - 12
Input voltage [V]
230
Suction port ["]
6/4, 2
Delivery port ["]
6/4, 2
Maximum current [A]
0.45 - 1.51
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
NO
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
180
