GRUNDFOS MAGNA3 PN16 circulator pump with flange

The Grundfos MAGNA3 circulator pump is the premium choice when system control and monitoring is key. MAGNA3 supports fieldbus by optional CIM modules and has a TFT display for intuitive configuration of the intelligent features See more

Technical Specifications

Maximum flow [l/min]
133 - 1,200
Maximum head [m]
4 - 18
Input voltage [V]
230
Suction port ["]
DN32, DN40, DN50, DN65, DN80, DN100

Show all Tech Specs

on demand check availability

from 988.08 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Heating pumps
Product No.:
MAS000478

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Suction port ["]
  • Delivery port ["]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Protection [IP]
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Port-to-port length
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos MAGNA3 32-40F 220mm 230V PN16

Product No.: ZB00030145 Sale group: CEGBB EAN: 5710629850768 Manuf. No.: 98333832

on demand
check availability
Product availability
  • central warehouse 0 pcs

988.08 €

Check availability

Maximum flow [l/min]
133
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
0,61
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 32-60F 220mm 230V PN16

Product No.: ZB00030149 Sale group: CEGBB EAN: 5710629850966 Manuf. No.: 98333852

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,155.12 €

Check availability

Maximum flow [l/min]
166
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
0,91
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 32-80F 220mm 230V PN16

Product No.: ZB00030152 Sale group: CEGBB EAN: 5710629851161 Manuf. No.: 98333872

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,217.02 €

Check availability

Maximum flow [l/min]
183
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
1,19
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 32-100F 220mm 230V PN16

Product No.: ZB00030142 Sale group: CEGBB EAN: 5710626493395 Manuf. No.: 97924264

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,384.06 €

Check availability

Maximum flow [l/min]
200
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
1,47
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 32-120F 220mm 230V PN16

Product No.: ZB00002270 Sale group: CEGBB EAN: 5710626493401 Manuf. No.: 97924265

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,685.34 €

Check availability

Maximum flow [l/min]
350
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN32
Delivery port ["]
DN32
Maximum current [A]
1,55
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 40-40F 220mm 230V PN16

Product No.: ZB00030160 Sale group: CEGBB EAN: 5710626493487 Manuf. No.: 97924273

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,232.45 €

Check availability

Maximum flow [l/min]
216
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
0,87
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 40-60F 220mm 230V PN16

Product No.: ZB00030162 Sale group: CEGBB EAN: 5710626493494 Manuf. No.: 97924274

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,340.26 €

Check availability

Maximum flow [l/min]
266
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1,58
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 40-80F 220mm 230V PN16

Product No.: ZB00002314 Sale group: CEGBB EAN: 5710626493500 Manuf. No.: 97924275

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,670.77 €

Check availability

Maximum flow [l/min]
333
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1,26
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 40-100F 220mm 230V PN16

Product No.: ZB00030154 Sale group: CEGBB EAN: 5710626493517 Manuf. No.: 97924276

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,842.47 €

Check availability

Maximum flow [l/min]
366
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1,66
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220

Grundfos MAGNA3 40-120F 250mm 230V PN16

Product No.: ZB00002276 Sale group: CEGBB EAN: 5710626493524 Manuf. No.: 97924277

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,106.65 €

Check availability

Maximum flow [l/min]
433
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
1,96
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
250

Grundfos MAGNA3 40-150F 250mm 230V PN16

Product No.: ZB00030156 Sale group: CEGBB EAN: 5710626493531 Manuf. No.: 97924278

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,497.97 €

Check availability

Maximum flow [l/min]
500
Maximum head [m]
15
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
2,78
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
250

Grundfos MAGNA3 40-180F 250mm 230V PN16

Product No.: ZB00030158 Sale group: CEGBB EAN: 5710626493548 Manuf. No.: 97924279

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,871.31 €

Check availability

Maximum flow [l/min]
500
Maximum head [m]
15
Input voltage [V]
230
Suction port ["]
DN40
Delivery port ["]
DN40
Maximum current [A]
2,78
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
250

Grundfos MAGNA3 50-40F 240mm 230V PN16

Product No.: ZB00030171 Sale group: CEGBB EAN: 5710626493623 Manuf. No.: 97924287

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,842.54 €

Check availability

Maximum flow [l/min]
333
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
0,72
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
240

Grundfos MAGNA3 50-60F 240mm 230V PN16

Product No.: ZB00030172 Sale group: CEGBB EAN: 5710626493630 Manuf. No.: 97924288

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,169.97 €

Check availability

Maximum flow [l/min]
433
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
1,18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
240

Grundfos MAGNA3 50-80F 240mm 230V PN16

Product No.: ZB00030173 Sale group: CEGBB EAN: 5710626493647 Manuf. No.: 97924289

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,388.92 €

Check availability

Maximum flow [l/min]
500
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
1,53
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
240

Grundfos MAGNA3 50-100F 280mm 230V PN16

Product No.: ZB00030164 Sale group: CEGBB EAN: 5710626493654 Manuf. No.: 97924290

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,527.38 €

Check availability

Maximum flow [l/min]
500
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
1,86
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA3 50-120F 280mm 230V PN16

Product No.: ZB00014732 Sale group: CEGBB EAN: 5710626493661 Manuf. No.: 97924291

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,667.80 €

Check availability

Maximum flow [l/min]
583
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
2,30
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA3 50-150F 280mm 230V PN16

Product No.: ZB00030167 Sale group: CEGBB EAN: 5710626493678 Manuf. No.: 97924292

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,073.14 €

Check availability

Maximum flow [l/min]
616
Maximum head [m]
15
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
2,75
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA3 50-180F 280mm 230V PN16

Product No.: ZB00030169 Sale group: CEGBB EAN: 5710626493685 Manuf. No.: 97924293

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,604.21 €

Check availability

Maximum flow [l/min]
666
Maximum head [m]
18
Input voltage [V]
230
Suction port ["]
DN50
Delivery port ["]
DN50
Maximum current [A]
3,45
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
280

Grundfos MAGNA3 65-40F 340mm 230V PN16

Product No.: ZB00030178 Sale group: CEGBB EAN: 5710626493753 Manuf. No.: 97924300

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,309.92 €

Check availability

Maximum flow [l/min]
466
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
0,94
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA3 65-60F 340mm 230V PN16

Product No.: ZB00002290 Sale group: CEGBB EAN: 5710626493760 Manuf. No.: 97924301

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,637.34 €

Check availability

Maximum flow [l/min]
583
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
1,64
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA3 65-80F 340mm 230V PN16

Product No.: ZB00030181 Sale group: CEGBB EAN: 5710626493777 Manuf. No.: 97924302

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,871.66 €

Check availability

Maximum flow [l/min]
666
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
2,11
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA3 65-100F 340mm 230V PN16

Product No.: ZB00030175 Sale group: CEGBB EAN: 5710626493784 Manuf. No.: 97924303

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,026.06 €

Check availability

Maximum flow [l/min]
716
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
2,74
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA3 65-120F 340mm 230V PN16

Product No.: ZB00030176 Sale group: CEGBB EAN: 5710626493791 Manuf. No.: 97924304

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,247.00 €

Check availability

Maximum flow [l/min]
766
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
3,45
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA3 65-150F 340mm 230V PN16

Product No.: ZB00014733 Sale group: CEGBB EAN: 5710626493807 Manuf. No.: 97924305

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,798.78 €

Check availability

Maximum flow [l/min]
1 000
Maximum head [m]
15
Input voltage [V]
230
Suction port ["]
DN65
Delivery port ["]
DN65
Maximum current [A]
6,18
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
340

Grundfos MAGNA3 80-40F 360mm 230V PN16

Product No.: ZB00030186 Sale group: CEGBB EAN: 5710626494026 Manuf. No.: 97924326

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,764.17 €

Check availability

Maximum flow [l/min]
616
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN80
Delivery port ["]
DN80
Maximum current [A]
1,52
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
360

Grundfos MAGNA3 80-60F 360mm 230V PN16

Product No.: ZB00030188 Sale group: CEGBB EAN: 5710626494033 Manuf. No.: 97924327

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,042.35 €

Check availability

Maximum flow [l/min]
750
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN80
Delivery port ["]
DN80
Maximum current [A]
2,40
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
360

Grundfos MAGNA3 80-80F 360mm 230V PN16

Product No.: ZB00030189 Sale group: CEGBB EAN: 5710626494040 Manuf. No.: 97924328

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,277.41 €

Not sellable online

Maximum flow [l/min]
866
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN80
Delivery port ["]
DN80
Maximum current [A]
3,15
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
360

Grundfos MAGNA3 80-100F 360mm 230V PN16

Product No.: ZB00030183 Sale group: CEGBB EAN: 5710626494057 Manuf. No.: 97924329

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,627.52 €

Not sellable online

Maximum flow [l/min]
1 016
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN80
Delivery port ["]
DN80
Maximum current [A]
4,69
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
360

Grundfos MAGNA3 80-120F 360mm 230V PN16

Product No.: ZB00030184 Sale group: CEGBB EAN: 5710626494064 Manuf. No.: 97924330

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,068.75 €

Not sellable online

Maximum flow [l/min]
1 166
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN80
Delivery port ["]
DN80
Maximum current [A]
6,65
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
360

Grundfos MAGNA3 100-40F 450mm 230V PN16

Product No.: ZB00030132 Sale group: CEGBB EAN: 5710626494071 Manuf. No.: 97924331

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,247.78 €

Not sellable online

Maximum flow [l/min]
750
Maximum head [m]
4
Input voltage [V]
230
Suction port ["]
DN100
Delivery port ["]
DN100
Maximum current [A]
2,35
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
450

Grundfos MAGNA3 100-60F 450mm 230V PN16

Product No.: ZB00030134 Sale group: CEGBB EAN: 5710626494088 Manuf. No.: 97924332

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,544.60 €

Not sellable online

Maximum flow [l/min]
833
Maximum head [m]
6
Input voltage [V]
230
Suction port ["]
DN100
Delivery port ["]
DN100
Maximum current [A]
3,11
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
450

Grundfos MAGNA3 100-80F 450mm 230V PN16

Product No.: ZB00014739 Sale group: CEGBB EAN: 5710626494095 Manuf. No.: 97924333

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,896.66 €

Not sellable online

Maximum flow [l/min]
1 083
Maximum head [m]
8
Input voltage [V]
230
Suction port ["]
DN100
Delivery port ["]
DN100
Maximum current [A]
5,06
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
450

Grundfos MAGNA3 100-100F 450mm 230V PN16

Product No.: ZB00030130 Sale group: CEGBB EAN: 5710626494101 Manuf. No.: 97924334

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,242.05 €

Not sellable online

Maximum flow [l/min]
1 166
Maximum head [m]
10
Input voltage [V]
230
Suction port ["]
DN100
Delivery port ["]
DN100
Maximum current [A]
6,17
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
450

Grundfos MAGNA3 100-120F 450mm 230V PN16

Product No.: ZB00030131 Sale group: CEGBB EAN: 5710626494118 Manuf. No.: 97924335

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,815.05 €

Not sellable online

Maximum flow [l/min]
1 200
Maximum head [m]
12
Input voltage [V]
230
Suction port ["]
DN100
Delivery port ["]
DN100
Maximum current [A]
7
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
450

Product description

MAGNA3 is an intelligent, high-efficiency circulator pump

The MAGNA3 circulator is a highly-advanced canned rotor pump intended for large commercial buildings such as hospitals and schools. Intelligent features such as AUTOADAPT and FLOWADAPT select the optimal system setting, ensuring that your system always provides the best possible comfort and the most efficient operation.

Connect the pump to a building management system and get complete control and monitoring of the system and improve reliability at the same time. You can also use the Grundfos GO Remote for monitoring purposes, giving you access to system data right at your fingertips.

MAGNA3 also offers multi-pump functionality, in which two pumps are connected in parallel. Multi-pump systems can operate in alternating, backup or cascade operation.

Save energy and time with intelligent control

Intelligent control modes such as AUTOADAPT result in significant energy savings.

Inputs and outputs ensure better system monitoring and optimal pump regulation.

MAGNA3 is an all-purpose circulator, ideal for applications such as heating, cooling and domestic hot water.

MAGNA3, More than a pump

The MAGNA3 is a circulator pump based on the tried and tested MAGNA technology and our industry-leading experience with electronic pumps. The permanent magnet motor, AUTOadapt function and integrated frequency converter is still part of the MAGNA package, but we’ve added some additional, ground-breaking new technologies. The result is a cutting-edge piece of intelligent technology that retains the unrivalled Grundfos reliability.

Instructions

Technical Specifications

Maximum flow [l/min]
133 - 1,200
Maximum head [m]
4 - 18
Input voltage [V]
230
Suction port ["]
DN32, DN40, DN50, DN65, DN80, DN100
Delivery port ["]
DN32, DN40, DN50, DN65, DN80, DN100
Maximum current [A]
0.61 - 7
Maximum liquid temperature [°C]
110
Protection [IP]
X4
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
integrated
Impeller material
noryl
Port-to-port length
220, 250, 240, 280, 340, 360, 450
