Grundfos Sololift2 C-3 230V automatic lifting stations up to 90 deg.C (3 sources)

Grundfos SOLOLIFT2 are small, compact, ready-to-install automatic lifting stations with integrated powerful cutter systems. Suitable for pumping wastewater with feces from private dwellings. The unit is designed according to EN 12050-3 See more

Technical Specifications

Maximum flow [l/min]
204
Maximum head [m]
8.50
Input voltage [V]
230
Power output - P2 [kW]
0.42

Show all Tech Specs

on demand check availability

431.48 € VAT included

On demand

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Sewage lifting stations
Product No.:
ZB00002623
Sale group:
CEGJ
EAN:
5710624187265
Manuf. No.:
97775317

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Power input - P1 [kW]
  • Drinking water certificate
  • Vessel volume [l]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos Sololift2 C-3 230V automatic lifting stations up to 90 deg.C (3 sources)

Product No.: ZB00002623 Sale group: CEGJ EAN: 5710624187265 Manuf. No.: 97775317

on demand
check availability
Product availability
  • central warehouse 0 pcs

431.48 €

Check availability

Maximum flow [l/min]
204
Maximum head [m]
8.50
Input voltage [V]
230
Power output - P2 [kW]
0.42
Power input - P1 [kW]
0.64
Drinking water certificate
NO
Vessel volume [l]
6
Maximum current [A]
3.10
Maximum liquid temperature [°C]
75
Cable length [m]
1.20
Protection [IP]
44
Automatic thermal protection
YES
Dry run protection
YES
Speed ​​control
NO
Capacitor
integrated
Impeller material
noryl
Construction
with centrifugal pumps
Grinder
NO
You are viewing this variant

Product description

Sololift2 C-3 is a small, compact automatic lifting station suitable for pumping of greywater (w/o faeces) off places in private dwellings where wastewater cannot be led directly to the sewer by means of a natural downward slope.

Sololift2 C-3 is typically used for:

  • cabinet showers, washbasins, bath tubs, washing machines (max. 90°C) and dishwashers in basements below sewer level or in connection with the renovation or modernisation of existing buildings, where the location may be remote from the main soil pipe so that a natural slope cannot be established.

Sololift2 C-3 is suitable for installation under a washbasin or particularly for confined space conditions in prewall constructions and built-in cabinets. Extremely low switching levels for lowest construction heights, advantageously in case of connection of a shower receptor.

The compact lifting station is equipped with

  • Cable with or without plug (see technical data)
  • Horizontal or vertical fastening possibility of discharge hose connector with several adaptors for pipes with Ø22-40mm
  • Integrated non return valve
  • Dry and high performance motor unit incl. thermal protection, level switch and controller
  • Flexible connectors for inlet (adjustable in height) of pipes Ø36 or 40
  • Manual anti clogging function and separate drain connection for service
  • Venting valve with overflow protection
  • Uplift fixation clips

Design according to EN12050-2 and production inspection by external institute with unique features focused on quick installation, long lasting operation and easy clean service.

Instructions

Technical Specifications

Maximum flow [l/min]
204
Maximum head [m]
8.50
Input voltage [V]
230
Power output - P2 [kW]
0.42
Power input - P1 [kW]
0.64
Drinking water certificate
NO
Vessel volume [l]
6
Maximum current [A]
3.10
Maximum liquid temperature [°C]
75
Cable length [m]
1.20
Protection [IP]
44
Automatic thermal protection
YES
Dry run protection
YES
Speed ​​control
NO
Capacitor
integrated
Impeller material
noryl
Construction
with centrifugal pumps
Grinder
NO
