Grundfos SP 11-27 5,5kW 400V Rp2 "submersible pump

Grundfos SP are submersible borehole pumps, designed for pumping groundwater. Grundfos SP are all stainless-steel pumps, and they are available in 3 material grades. The pumps are suitable for boreholes in sizes ranging 4". The motor sizes for the pumps are available in 0.37-250 kW See more

Technical Specifications

Maximum flow [l/min]
233
Maximum head [m]
162
Input voltage [V]
3x400
Power output - P2 [kW]
5.50

Show all Tech Specs

on demand check availability

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us by email [email protected]

3,631.32 € VAT included

Not sellable online

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Submersible borehole pumps
Product No.:
ZB00066035
Sale group:
CEGWG
EAN:
5712603248615
Manuf. No.:
98900420

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos SP 11-3 0.75kW 400V Rp2 "submersible pump

Product No.: ZB00067423 Sale group: CEGWG EAN: 5712600111073 Manuf. No.: 98699312

on demand
check availability
Product availability
  • central warehouse 0 pcs

893.28 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
18
Input voltage [V]
3x400
Power output - P2 [kW]
0.75
Rated flow [l/m]
150
Rated head [m]
12
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
2.30
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-5 1,1kW 400V Rp2 "submersible pump

Product No.: ZB00067425 Sale group: CEGWG EAN: 5712600111097 Manuf. No.: 98699313

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,101.64 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
30
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Rated flow [l/m]
150
Rated head [m]
20
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
3.40
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-7 1,5kW 400V Rp2 "submersible pump

Product No.: ZB00055838 Sale group: CEGWG EAN: 5712600111110 Manuf. No.: 98699314

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,328.03 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
42
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Rated flow [l/m]
150
Rated head [m]
27
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
4.20
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-11 2.2kW 400V Rp2 "submersible pump

Product No.: ZB00030725 Sale group: CEGWG EAN: 5712600111134 Manuf. No.: 98699315

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,764.94 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
66
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
5.50
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-15A 3.0kW 400V Rp2 "submersible pump

Product No.: ZB00047615 Sale group: CEGWG EAN: 5712600111158 Manuf. No.: 98699316

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,424.93 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
90
Input voltage [V]
3x400
Power output - P2 [kW]
3
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
7.85
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-20 4,0kW 400V Rp2 "submersible pump

Product No.: ZB00067421 Sale group: CEGWG EAN: 5712600111172 Manuf. No.: 98699317

on demand
check availability
Product availability
  • central warehouse 0 pcs

2,954.33 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
120
Input voltage [V]
3x400
Power output - P2 [kW]
4
Rated flow [l/m]
150
Rated head [m]
78
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
9.60
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-24 5.5kW 400V Rp2 "submersible pump

Product No.: ZB00067161 Sale group: CEGWG EAN: 5712600111196 Manuf. No.: 98699318

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,409.54 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
145
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Rated flow [l/m]
150
Rated head [m]
94
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
13
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Grundfos SP 11-27 5,5kW 400V Rp2 "submersible pump

Product No.: ZB00066035 Sale group: CEGWG EAN: 5712603248615 Manuf. No.: 98900420

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,631.32 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
162
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Rated flow [l/m]
150
Rated head [m]
105
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
13
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal
You are viewing this variant

Grundfos SP 11-33 7,5kW 400V Rp2 "submersible pump

Product No.: ZB00067424 Sale group: CEGWG EAN: 5712600111233 Manuf. No.: 98699320

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,749.35 €

Not sellable online

Maximum flow [l/min]
233
Maximum head [m]
200
Input voltage [V]
3x400
Power output - P2 [kW]
7.50
Rated flow [l/m]
150
Rated head [m]
130
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
18.80
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal

Product description

The Grundfos SP submersible pump is a highly durable pump made of high-quality stainless steel.

Thanks to the optimized hydraulic design, SP provides optimal efficiency and low operating costs and high operational reliability. These pumps are suitable for various applications such as groundwater pumping in water management, irrigation, groundwater level reduction, pressure boosting and industrial applications.

Corrosion resistant

High-quality AISI 304 stainless steel, inside and out, makes the SP pump extremely corrosion-resistant.

Right solution

The SP submersible pump is available in many variants and sizes and can be adapted to the specific application.

Reverse throttle valve

Its built-in non-return valve minimizes the risk of water shock damage.

Instructions

Technical Specifications

Maximum flow [l/min]
233
Maximum head [m]
162
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Rated flow [l/m]
150
Rated head [m]
105
Delivery port ["]
2
Pump diameter ["]
4
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
13
Cable length [m]
1.70
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
101
Impeller material
stainless steel
Construction
centrifugal
