GRUNDFOS SQ 1 submersible groundwater pumps

Drinking water certificate

previous next
GRUNDFOS SQ 1 submersible groundwater pumps

Grundfos SQ pumps are compact submersible pumps, designed for domestic groundwater supply for private housing, small waterworks, and small irrigation systems See more

Technical Specifications

Maximum flow [l/min]
26
Maximum head [m]
45 - 230
Input voltage [V]
230
Power output - P2 [kW]
0.70 - 1.85

Show all Tech Specs

in stock >10 pcs

from 886.45 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
Grundfos
Category:
Submersible borehole pumps
Product No.:
MAS000538

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Grundfos SQ1-35 230V 3" submersible groundwater pump

Product No.: ZB00014819 Sale group: CEGWJ EAN: 5700396503776 Manuf. No.: 96510178

on demand
check availability
Product availability
  • central warehouse 0 pcs

886.45 €

Check availability

Maximum flow [l/min]
26
Maximum head [m]
45
Input voltage [V]
230
Power output - P2 [kW]
0.70
Rated flow [l/m]
16
Rated head [m]
29
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
5.20
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-50 230V 3" submersible groundwater pump

Product No.: ZB00014824 Sale group: CEGWJ EAN: 5700396503783 Manuf. No.: 96510179

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

957.59 €

Maximum flow [l/min]
26
Maximum head [m]
70
Input voltage [V]
230
Power output - P2 [kW]
0.70
Rated flow [l/m]
16
Rated head [m]
46
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
5.20
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-65 230V 3" submersible groundwater pump

Product No.: ZB00015082 Sale group: CEGWJ EAN: 5700396503790 Manuf. No.: 96510190

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,030.92 €

Maximum flow [l/min]
26
Maximum head [m]
90
Input voltage [V]
230
Power output - P2 [kW]
0.70
Rated flow [l/m]
16
Rated head [m]
59
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
5.20
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-65 230V 3" submersible groundwater pump, 30m cable

Product No.: ZB00040200 Sale group: CEGJ1 EAN: 5700396929705 Manuf. No.: 96524421

in stock
9 pcs
Product availability
  • central warehouse 9 pcs

1,130.24 €

Maximum flow [l/min]
26
Maximum head [m]
90
Input voltage [V]
230
Power output - P2 [kW]
0.70
Rated flow [l/m]
16
Rated head [m]
59
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
5.20
Maximum liquid temperature [°C]
35
Cable length [m]
30
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-80 230V 3" submersible groundwater pump

Product No.: ZB00015083 Sale group: CEGWJ EAN: 5700396503806 Manuf. No.: 96510191

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,243.64 €

Maximum flow [l/min]
26
Maximum head [m]
110
Input voltage [V]
230
Power output - P2 [kW]
1.15
Rated flow [l/m]
16
Rated head [m]
72
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
8.40
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-95 230V 3" submersible groundwater pump

Product No.: ZB00030755 Sale group: CEGWJ EAN: 5700396504018 Manuf. No.: 96510192

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,295.18 €

Maximum flow [l/min]
26
Maximum head [m]
140
Input voltage [V]
230
Power output - P2 [kW]
1.15
Rated flow [l/m]
16
Rated head [m]
91
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
8.40
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-110 230V 3" submersible groundwater pump

Product No.: ZB00015228 Sale group: CEGWJ EAN: 5700396504025 Manuf. No.: 96510193

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,346.73 €

Maximum flow [l/min]
26
Maximum head [m]
160
Input voltage [V]
230
Power output - P2 [kW]
1.15
Rated flow [l/m]
16
Rated head [m]
104
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
8.40
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-140 230V 3" submersible groundwater pump

Product No.: ZB00030754 Sale group: CEGWJ EAN: 5700396504049 Manuf. No.: 96510195

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

1,658.18 €

Maximum flow [l/min]
26
Maximum head [m]
210
Input voltage [V]
230
Power output - P2 [kW]
1.55
Rated flow [l/m]
16
Rated head [m]
137
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
11.20
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Grundfos SQ1-155 230V 3" submersible groundwater pump

Product No.: ZB00015099 Sale group: CEGWJ EAN: 5700396504056 Manuf. No.: 96510196

in stock
2 pcs
Product availability
  • central warehouse 2 pcs

1,709.73 €

Maximum flow [l/min]
26
Maximum head [m]
230
Input voltage [V]
230
Power output - P2 [kW]
1.85
Rated flow [l/m]
16
Rated head [m]
150
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
12.30
Maximum liquid temperature [°C]
35
Cable length [m]
1.50
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal

Product description

3" multi-stage, submersible pump designed for domestic water supply, liquid transfer in tanks, irrigation and environmental applications. The pump has "floating" impellers, each with its own tungsten carbide/ceramic bearing.

The pump features soft starting and protection against dry-running, upthrust, overvoltage, undervoltage, overload and overtemperature.

The motor is a single-phase motor of the permanent magnet rotor type ensuring optimum efficiency within a wide load range. The motor is fitted with a replaceable end cover with socket.

Instructions

Technical Specifications

Maximum flow [l/min]
26
Maximum head [m]
45 - 230
Input voltage [V]
230
Power output - P2 [kW]
0.70 - 1.85
Rated flow [l/m]
16
Rated head [m]
29 - 150
Delivery port ["]
5/4
Pump diameter ["]
3
Maximum immersion depth [m]
150
Drinking water certificate
YES
Float switch
NO
Maximum current [A]
5.20 - 12.30
Maximum liquid temperature [°C]
35
Cable length [m]
1.50 - 30
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Maximum borehole diameter [mm]
74
Impeller material
noryl
Construction
centrifugal
