PUMPA black line BLC sewage grinder pump 3x400V

PUMPA black line BLC sewage grinder pump 3x400V

Submersible sewage grinder pump for domestic use. Suitable for pumping wastewater containing coarse impurities, without abrasive additives. See more

Technical Specifications

Maximum flow [l/min]
217 - 417
Maximum head [m]
17 - 42
Input voltage [V]
3x400
Power output - P2 [kW]
1.10 - 5.50

Show all Tech Specs

from 436.84 VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
MAS001037

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

Maximum flow [l/min]
217
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
DN40
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
2.80
Maximum liquid temperature [°C]
40
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
YES
Maximum flow [l/min]
300
Maximum head [m]
18
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Delivery port ["]
DN40
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
3.20
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
YES
Maximum flow [l/min]
333
Maximum head [m]
26
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Delivery port ["]
DN40
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
5
Cable length [m]
8
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
YES
Maximum flow [l/min]
417
Maximum head [m]
30
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
8.50
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
YES
Maximum flow [l/min]
417
Maximum head [m]
42
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
YES

Product description

Description

Submersible sewage grinder pump for domestic use. Suitable for pumping wastewater containing coarse impurities, without abrasive additives.

Application

  • wastewater drainage
  • for household and industrial applications

Variants

  • with float (label - S)
  • without float

Technical Specifications

Maximum flow [l/min]
217 - 417
Maximum head [m]
17 - 42
Input voltage [V]
3x400
Power output - P2 [kW]
1.10 - 5.50
Delivery port ["]
DN40, DN50
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
2.80 - 11.70
Maximum liquid temperature [°C]
40
Cable length [m]
8 - 15
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
YES
