PUMPA black line BLK HT sludge pump

New

previous next
PUMPA black line BLK HT sludge pump

High-temperature sludge pump with channel impeller for pumping wastewater and liquids up to 80°C. The HT model is upgraded with insulation level, rubber material, bearings and lubrication. See more

Technical Specifications

Maximum flow [l/min]
550 - 750
Maximum head [m]
15 - 26
Input voltage [V]
3x400
Power output - P2 [kW]
1.10 - 3

Show all Tech Specs

in stock >10 pcs

from 399.59 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
MAS001643

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA black line 50BLK21.1 HT 400V 1,1kW, sludge pump, channel impeller, 25mm clearance, cable 15m, max. temperature 80°C

Product No.: ZB00072893 Sale group: CEBKP EAN: 8596455042334

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

399.59 €

Not sellable online

Maximum flow [l/min]
550
Maximum head [m]
15
Input voltage [V]
3x400
Power output - P2 [kW]
1.10
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
2.80
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
25
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 50BLK21.5 HT 400V 1,5kW, sludge pump, channel impeller, 20mm clearance, cable 15m, max. temperature 80°C

Product No.: ZB00072894 Sale group: CEBKP EAN: 8596455042341

in stock
5 pcs
Product availability
  • central warehouse 5 pcs

511.10 €

Not sellable online

Maximum flow [l/min]
616
Maximum head [m]
20
Input voltage [V]
3x400
Power output - P2 [kW]
1.50
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
3.20
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 50BLK22.2 HT 400V 2,2kW, sludge pump, channel impeller, 20mm clearance, cable 15m, max. temperature 80°C

Product No.: ZB00072895 Sale group: CEBKP EAN: 8596455042358

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

551.37 €

Not sellable online

Maximum flow [l/min]
666
Maximum head [m]
22
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
5
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 50BLK23.0 HT 400V 3,0kW, sludge pump, channel impeller, 20mm clearance, cable 15m, max. temperature 80°C

Product No.: ZB00072896 Sale group: CEBKP EAN: 8596455042365

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

678.37 €

Not sellable online

Maximum flow [l/min]
750
Maximum head [m]
26
Input voltage [V]
3x400
Power output - P2 [kW]
3
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6.50
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
20
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

High-temperature sludge pump with channel impeller for pumping wastewater and liquids up to 80°C. The HT model is upgraded with insulation level, rubber material, bearings and lubrication.

Applications

  • Wastewater pumping
  • Drainage water pumping
  • Rainwater pumping
  • Industrial applications, heating plants, laundries, etc.
  • pumping stations, sewage treatment plants


Installation options

  • Y installation - elbow with flange
  • Z installation - launching device

Technical Specifications

Maximum flow [l/min]
550 - 750
Maximum head [m]
15 - 26
Input voltage [V]
3x400
Power output - P2 [kW]
1.10 - 3
Delivery port ["]
DN50
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
2.80 - 6.50
Maximum liquid temperature [°C]
80
Cable length [m]
15
Maximum particle size [mm]
20 - 25
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
