PUMPA black line BLK sewage pump

Sewage pump with circulating channel wheel. Suitable for pumping wastewater containing coarse impurities. See more

Technical Specifications

Maximum flow [l/min]
1,217 - 3,333
Maximum head [m]
12 - 24
Input voltage [V]
3x400
Power output - P2 [kW]
2.20 - 7.50

Show all Tech Specs

in stock >10 pcs

from 1,092.76 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
MAS001041

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA black line 80BLK42.2 400V 2,2kW, sewage pump, channel impeller, max. particle size 50mm, cable 15m

Product No.: ZB00065214 Sale group: CEBKP EAN: 8596455036289

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,092.84 €

Not sellable online

Maximum flow [l/min]
1 217
Maximum head [m]
12
Input voltage [V]
3x400
Power output - P2 [kW]
2,20
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
5
Cable length [m]
15
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 80BLK43.7 400V 3,7kW, sewage pump, channel impeller, max. particle size 50mm, cable 15m

Product No.: ZB00065216 Sale group: CEBKP EAN: 8596455036302

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

1,326.06 €

Not sellable online

Maximum flow [l/min]
1,500
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Delivery port ["]
DN80
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
8.50
Cable length [m]
15
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMP black line 100BLK42.2 400V 2.2kW, sewage pump, channel impeller, throughput 50mm, cable 15m

Product No.: ZB00065215 Sale group: CEBKP EAN: 8596455036296

in stock
9 pcs
Product availability
  • central warehouse 9 pcs

1,092.76 €

Not sellable online

Maximum flow [l/min]
1,667
Maximum head [m]
12
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
5
Cable length [m]
8
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLK43.7 400V 3,7kW, sewage pump, channel impeller, passage 50mm, cabel 8m

Product No.: ZB00061140 Sale group: CEBKP EAN: 8596455020202

in stock
1 pcs
Product availability
  • central warehouse 1 pcs

1,319.45 €

Not sellable online

Maximum flow [l/min]
2,167
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
8.50
Cable length [m]
8
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLK43.7 400V 3,7kW, sewage pump, channel impeller, max. particle size 50mm, cable 15m

Product No.: ZB00065217 Sale group: CEBKP EAN: 8596455036319

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

1,326.14 €

Not sellable online

Maximum flow [l/min]
2,167
Maximum head [m]
17
Input voltage [V]
3x400
Power output - P2 [kW]
3.70
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
8.50
Cable length [m]
15
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLK45.5 WD 400V 5.5kW, sludge pump, channel impeller, throughput 50mm, cable 15m, with leakage sensor with stopper

Product No.: ZB00065224 Sale group: CEBKP EAN: 8596455036326

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

1,676.30 €

Not sellable online

Maximum flow [l/min]
2,500
Maximum head [m]
19
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
15
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 100BLK47.5 WD 400V 7,5kW, sewage pump, channel impeller, max. particle size 55mm, cable 15m, with leakage sensor with stopper

Product No.: ZB00065226 Sale group: CEBKP EAN: 8596455036340

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

2,020.77 €

Not sellable online

Maximum flow [l/min]
2,833
Maximum head [m]
24
Input voltage [V]
3x400
Power output - P2 [kW]
7.50
Delivery port ["]
DN100
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
15.70
Cable length [m]
15
Maximum particle size [mm]
50
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 150BLK45.5 WD 400V 5,5kW, sewage pump, channel impeller, max. particle size 55mm, cable 15m, with leakage sensor plug

Product No.: ZB00065225 Sale group: CEBKP EAN: 8596455036333

on demand
check availability
Product availability
  • central warehouse 0 pcs

1,743.45 €

Not sellable online

Maximum flow [l/min]
3,333
Maximum head [m]
16
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN150
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
11.70
Cable length [m]
15
Maximum particle size [mm]
55
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

Description

Slurry pump with circulating channel wheel. Suitable for pumping wastewater containing coarse impurities.

Use

  • wastewater pumping
  • drainage water pumping
  • rainwater pumping
  • industrial applications
  • gas stations, sewage treatment plants

Instructions

Technical Specifications

Maximum flow [l/min]
1,217 - 3,333
Maximum head [m]
12 - 24
Input voltage [V]
3x400
Power output - P2 [kW]
2.20 - 7.50
Delivery port ["]
DN80, DN100, DN150
Maximum immersion depth [m]
20
Float switch
NO
Maximum current [A]
5 - 15.70
Cable length [m]
8 - 15
Maximum particle size [mm]
50 - 55
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
