PUMPA black line BLV 2,2-5,5 kW sewage pump

previous next
PUMPA black line BLV 2,2-5,5 kW sewage pump

See more

Technical Specifications

Maximum flow [l/min]
583 - 1,166
Maximum head [m]
16 - 23
Input voltage [V]
3x400
Power output - P2 [kW]
2.20 - 5.50

Show all Tech Specs

in stock >10 pcs

from 520.72 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Sewage pumps
Product No.:
MAS001038

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA black line 65BLV22.2 400V 2,2kW, sewage pump, Vortex impeller, max. particle size 56mm, cable 15m

Product No.: ZB00065196 Sale group: CEBKP EAN: 8596455036135

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

520.72 €

Maximum flow [l/min]
583
Maximum head [m]
16
Input voltage [V]
3x400
Power output - P2 [kW]
2.20
Delivery port ["]
DN65
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
5
Cable length [m]
15
Maximum particle size [mm]
56
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 65BLV23.0 400V 3kW, sewage pump, Vortex impeller, max. particle size 56mm, cable 15m

Product No.: ZB00065199 Sale group: CEBKP EAN: 8596455036142

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

648.32 €

Not sellable online

Maximum flow [l/min]
667
Maximum head [m]
20
Input voltage [V]
3x400
Power output - P2 [kW]
3
Delivery port ["]
DN65
Maximum immersion depth [m]
10
Float switch
NO
Maximum current [A]
6.50
Cable length [m]
15
Maximum particle size [mm]
56
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 80BLV24.0 400V 4kW, sludge pump, Vortex impeller, throughput 56mm, cable 15m

Product No.: ZB00065206 Sale group: CEBKP EAN: 8596455036203

in stock
3 pcs
Product availability
  • central warehouse 3 pcs

811.89 €

Not sellable online

Maximum flow [l/min]
1,083
Maximum head [m]
21
Input voltage [V]
3x400
Power output - P2 [kW]
4
Delivery port ["]
DN80
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
8.90
Maximum liquid temperature [°C]
40
Cable length [m]
15
Maximum particle size [mm]
56
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA black line 80BLV25.5 400V 5,5kW, sewage pump, Vortex impeller, passage 56mm, cable 15m

Product No.: ZB00065207 Sale group: CEBKP EAN: 8596455036210

in stock
9 pcs
Product availability
  • central warehouse 9 pcs

1,029.13 €

Not sellable online

Maximum flow [l/min]
1,166
Maximum head [m]
23
Input voltage [V]
3x400
Power output - P2 [kW]
5.50
Delivery port ["]
DN80
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
11.70
Maximum liquid temperature [°C]
40
Cable length [m]
15
Maximum particle size [mm]
56
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

Product description

Instructions

Technical Specifications

Maximum flow [l/min]
583 - 1,166
Maximum head [m]
16 - 23
Input voltage [V]
3x400
Power output - P2 [kW]
2.20 - 5.50
Delivery port ["]
DN65, DN80
Maximum immersion depth [m]
10
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
5 - 11.70
Maximum liquid temperature [°C]
40
Cable length [m]
15
Maximum particle size [mm]
56
Protection [IP]
68
Automatic thermal protection
NO
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
