PUMPA black line Box 2 SE BLC XTREME pump sump

Czech product

previous next
PUMPA black line Box 2 SE BLC XTREME pump sump

See more

Technical Specifications

Maximum flow [l/min]
434 - 834
Maximum head [m]
17 - 30
Input voltage [V]
3x400
Delivery port ["]
DN50

Show all Tech Specs

on demand check availability

Goods cannot be purchased online. These are either oversized goods with an individual price of transport or an assortment that can only be purchased on demand. If you are interested in the goods, contact us by email [email protected]

from 3,821.47 € VAT included

Not sellable online

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Grinder pump stations with centrifugal pumps for industrial and municipal use
Product No.:
MAS001564

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Delivery port ["]
  • Drinking water certificate
  • Vessel volume [l]
  • Float switch
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMP black line Box 2 SE 40BLC1.1 XTREME pump sump including shaft and switch box, starting device, floats 4 pcs, 400V 1.1kW, cable 15m

Product No.: ZB00065654 Sale group: CJPU

on demand
check availability
Product availability
  • central warehouse 0 pcs

3,821.47 €

Not sellable online

Maximum flow [l/min]
434
Maximum head [m]
17
Input voltage [V]
3x400
Delivery port ["]
DN50
Drinking water certificate
NO
Vessel volume [l]
1000
Float switch
YES
Maximum liquid temperature [°C]
40
Cable length [m]
15
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
centrifugal
Grinder
YES

PUMPA black line Box 2 SE 40BLC1.5 XTREME pump sump including shaft and switch box, starting device, floats 4 pcs, 400V 1.5kW, cable 15m

Product No.: ZB00068295 Sale group: CJPU

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,254.36 €

Not sellable online

Maximum flow [l/min]
600
Maximum head [m]
18
Input voltage [V]
3x400
Delivery port ["]
DN50
Drinking water certificate
NO
Vessel volume [l]
1000
Float switch
YES
Maximum liquid temperature [°C]
40
Cable length [m]
15
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
centrifugal
Grinder
YES

PUMPA black line Box 2 SE 40BLC2.2 XTREME pump sump including shaft and switch box, starting device, floats 4 pcs, 400V 2.2kW, cable 15m

Product No.: ZB00068296 Sale group: CJPU

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,331.80 €

Not sellable online

Maximum flow [l/min]
666
Maximum head [m]
26
Input voltage [V]
3x400
Delivery port ["]
DN50
Drinking water certificate
NO
Vessel volume [l]
1000
Float switch
YES
Maximum liquid temperature [°C]
40
Cable length [m]
15
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
centrifugal
Grinder
YES

PUMPA black line Box 2 SE 50BLC3.7 XTREME pump tank including shaft and switch box, trigger, floats 4ks, 400V 3.7kW, cable 15m

Product No.: ZB00068297 Sale group: CJPU

on demand
check availability
Product availability
  • central warehouse 0 pcs

4,827.90 €

Not sellable online

Maximum flow [l/min]
834
Maximum head [m]
30
Input voltage [V]
3x400
Delivery port ["]
DN50
Drinking water certificate
NO
Vessel volume [l]
1000
Float switch
YES
Maximum liquid temperature [°C]
40
Cable length [m]
15
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
centrifugal
Grinder
YES

Product description

Instructions

Technical Specifications

Maximum flow [l/min]
434 - 834
Maximum head [m]
17 - 30
Input voltage [V]
3x400
Delivery port ["]
DN50
Drinking water certificate
NO
Vessel volume [l]
1000
Float switch
YES
Maximum liquid temperature [°C]
40
Cable length [m]
15
Protection [IP]
55
Automatic thermal protection
NO
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
centrifugal
Grinder
YES
