PUMPA
Technical Specifications
- Maximum flow [l/min]
- 60
- Maximum head [m]
- 45
- Input voltage [V]
- 230
- Power output - P2 [kW]
- 0.75
from 307.42 € VAT included
- Brand:
- PUMPA
- Category:
- Pressure booster pumps with expansion vessel for domestic use
- Product No.:
- MAS000044
Product variants
-
- PUMPA blue line pressure booster pump PJM101C PWB24H-24l horizontal 230V 2,1-3,5bar
- ZB00001169
- 60
- 45
- 230
- 0,75
- 1
- 1
- 8
- NO
- 24
- 5,50
- 35
- 2,1
- 3,5
- YES
- NO
- NO
- NO
- integrated
- noryl
- with expansion vessel
-
Product availability
- central warehouse 5 pcs
- available within 5 working days >50 pcs
- 307.42 €
- Not sellable online
-
- PUMPA blue line pressure booster pump PJM101C PWB35H-35l horizontal 230V 2,1-3,5bar
- ZB00001170
- 60
- 45
- 230
- 0,75
- 1
- 1
- 8
- NO
- 35
- 5,50
- 35
- 2,1
- 3,5
- YES
- NO
- NO
- NO
- integrated
- noryl
- with expansion vessel
-
Product availability
- central warehouse 5 pcs
- available within 5 working days >50 pcs
- 341.63 €
- Not sellable online
-
- PUMPA blue line pressure booster pump PJM101C PWB60H-60l horizontal 230V 2,1-3,5bar
- ZB00001171
- 60
- 45
- 230
- 0,75
- 1
- 1
- 8
- NO
- 60
- 5,50
- 35
- 2,1
- 3,5
- YES
- NO
- NO
- NO
- integrated
- noryl
- with expansion vessel
-
Product availability
- central warehouse >10 pcs
- available within 5 working days >50 pcs
- 386.26 €
- Not sellable online
Variant Product No.
Availability
Price (VAT incl.)
PUMPA blue line pressure booster pump PJM101C PWB24H-24l horizontal 230V 2,1-3,5bar
Product No.: ZB00001169 Sale group: CEBL EAN: 8596455001751
307.42 €
- Maximum flow [l/min]
- 60
- Maximum head [m]
- 45
- Input voltage [V]
- 230
- Power output - P2 [kW]
- 0,75
- Suction port ["]
- 1
- Delivery port ["]
- 1
- Maximum suction lift [m]
- 8
- Drinking water certificate
- NO
- Vessel volume [l]
- 24
- Maximum current [A]
- 5,50
- Maximum liquid temperature [°C]
- 35
- Start pressure [bar]
- 2,1
- Stop pressure [bar]
- 3,5
- Automatic thermal protection
- YES
- Dry run protection
- NO
- Off switch
- NO
- Speed control
- NO
- Capacitor
- integrated
- Impeller material
- noryl
- Construction
- with expansion vessel
PUMPA blue line pressure booster pump PJM101C PWB35H-35l horizontal 230V 2,1-3,5bar
Product No.: ZB00001170 Sale group: CEBL EAN: 8596455001768
341.63 €
- Maximum flow [l/min]
- 60
- Maximum head [m]
- 45
- Input voltage [V]
- 230
- Power output - P2 [kW]
- 0,75
- Suction port ["]
- 1
- Delivery port ["]
- 1
- Maximum suction lift [m]
- 8
- Drinking water certificate
- NO
- Vessel volume [l]
- 35
- Maximum current [A]
- 5,50
- Maximum liquid temperature [°C]
- 35
- Start pressure [bar]
- 2,1
- Stop pressure [bar]
- 3,5
- Automatic thermal protection
- YES
- Dry run protection
- NO
- Off switch
- NO
- Speed control
- NO
- Capacitor
- integrated
- Impeller material
- noryl
- Construction
- with expansion vessel
PUMPA blue line pressure booster pump PJM101C PWB60H-60l horizontal 230V 2,1-3,5bar
Product No.: ZB00001171 Sale group: CEBL EAN: 8596455001775
386.26 €
- Maximum flow [l/min]
- 60
- Maximum head [m]
- 45
- Input voltage [V]
- 230
- Power output - P2 [kW]
- 0,75
- Suction port ["]
- 1
- Delivery port ["]
- 1
- Maximum suction lift [m]
- 8
- Drinking water certificate
- NO
- Vessel volume [l]
- 60
- Maximum current [A]
- 5,50
- Maximum liquid temperature [°C]
- 35
- Start pressure [bar]
- 2,1
- Stop pressure [bar]
- 3,5
- Automatic thermal protection
- YES
- Dry run protection
- NO
- Off switch
- NO
- Speed control
- NO
- Capacitor
- integrated
- Impeller material
- noryl
- Construction
- with expansion vessel
Product description
Instructions
Technical Specifications
- Maximum flow [l/min]
- 60
- Maximum head [m]
- 45
- Input voltage [V]
- 230
- Power output - P2 [kW]
- 0.75
- Suction port ["]
- 1
- Delivery port ["]
- 1
- Maximum suction lift [m]
- 8
- Drinking water certificate
- NO
- Vessel volume [l]
- 24, 35, 60
- Maximum current [A]
- 5.50
- Maximum liquid temperature [°C]
- 35
- Start pressure [bar]
- 2,1
- Stop pressure [bar]
- 3,5
- Automatic thermal protection
- YES
- Dry run protection
- NO
- Off switch
- NO
- Speed control
- NO
- Capacitor
- integrated
- Impeller material
- noryl
- Construction
- with expansion vessel
