PUMPA blue line PQD7-16-1.5QGF 230V sewage pump with grinder, float switch, switch box, cable 10m

Submersible sewage pumps with a cutting device for pumping heavily polluted water, sludge, sewage, septic tanks, etc. Max. temperature of pumped fluid 35°C, max. draught 10 m. Designed for 230 V including thermal overload protection built into the pump. Pumps is equipped with a float, a 10 m cable and a fork. See more

Technical Specifications

Maximum flow [l/min]
315
Maximum head [m]
19
Input voltage [V]
230
Power output - P2 [kW]
1.50

Show all Tech Specs

on demand check availability

244.52 € VAT included

On demand

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Wastewater pumps
Product No.:
ZB00039581
Sale group:
CEBL
EAN:
8596455002215

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA blue line PQD7-8-0.75QGF 230V sewage pump with grinder, float switch, switch box, cable 10m

Product No.: ZB00039579 Sale group: CEBL EAN: 8596455000228

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

217.31 €

Maximum flow [l/min]
250
Maximum head [m]
12
Input voltage [V]
230
Power output - P2 [kW]
0.75
Delivery port ["]
2
Maximum immersion depth [m]
5
Drinking water certificate
NO
Float switch
YES
Maximum current [A]
5.20
Maximum liquid temperature [°C]
35
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Impeller material
cast iron
Construction
submersible
Grinder
YES

PUMPA blue line PQD7-12-1.1QGF 230V sewage pump with grinder, float switch, switch box, cable 10m

Product No.: ZB00039580 Sale group: CEBL EAN: 8596455002208

in stock
>50 pcs
Product availability
  • central warehouse >50 pcs

227.52 €

Maximum flow [l/min]
300
Maximum head [m]
15
Input voltage [V]
230
Power output - P2 [kW]
1.10
Delivery port ["]
2
Maximum immersion depth [m]
5
Drinking water certificate
NO
Float switch
YES
Maximum current [A]
7.30
Maximum liquid temperature [°C]
35
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Impeller material
cast iron
Construction
submersible
Grinder
YES

PUMPA blue line PQD7-16-1.5QGF 230V sewage pump with grinder, float switch, switch box, cable 10m

Product No.: ZB00039581 Sale group: CEBL EAN: 8596455002215

on demand
check availability
Product availability
  • central warehouse 0 pcs

244.52 €

Check availability

Maximum flow [l/min]
315
Maximum head [m]
19
Input voltage [V]
230
Power output - P2 [kW]
1.50
Delivery port ["]
2
Maximum immersion depth [m]
5
Drinking water certificate
NO
Float switch
YES
Maximum current [A]
9.50
Maximum liquid temperature [°C]
35
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Impeller material
cast iron
Construction
submersible
Grinder
YES
You are viewing this variant

Product description

Use of the pump PUMPA blue line PQD

  • for pumping heavily polluted water, sludge, sewage, septic tanks, etc.

Instructions

Technical Specifications

Maximum flow [l/min]
315
Maximum head [m]
19
Input voltage [V]
230
Power output - P2 [kW]
1.50
Delivery port ["]
2
Maximum immersion depth [m]
5
Drinking water certificate
NO
Float switch
YES
Maximum current [A]
9.50
Maximum liquid temperature [°C]
35
Cable length [m]
10
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
YES
Speed ​​control
NO
Capacitor
external
Impeller material
cast iron
Construction
submersible
Grinder
YES
