PUMPA blue line PRO PSXM drainage pump 230V

{64831361-D17E-45BD-B78C-1F5A24C07CB6} {C1BB24AE-54A9-4BCB-AEAB-87BE18753BE9}
PUMPA blue line PRO PSXM drainage pump 230V

Submersible drainage pump. Designed for pumping drainage water in the fields of civil engineering, such as mines, quarries, suitable for draining flooded rooms or pumping out reservoirs, ponds, etc. {1CF88B65-E656-42A4-91BE-75648B112E77}

{8A8BE3E9-621D-4576-8D55-B6DC70614F58}

Maximum flow [l/min]
500
Maximum head [m]
21
Input voltage [V]
230
Power output - P2 [kW]
1.50

{5438E0C9-7758-4682-AC69-D7336A66B255}

{61BA0C9D-4F27-4AB5-AA0F-987999C382E0} >50 {D6541EE7-57DD-49C9-90E1-FC33E80E484A}

{3BABE24A-A476-4762-ABDA-AE77F5115760} 706.06 € {AA16D06D-1F27-46F4-8DC5-EDAD5DF688EE}

{86644E1A-1010-44C9-AF12-FDF4EF9221BD}

{597808EC-D43C-433B-9E27-34C5C58E914E} {0DE80C11-45D7-44C5-AC3D-B08EB13AA33A}

{B6F75A89-5D63-4C1B-BFF2-DE3D944B6827}:
PUMPA
{1BE44D55-5356-4F2C-8815-F93F46DB7B28}:
Wastewater pumps
{B00C0DC4-D2B5-4EEA-9C99-AE65FE098F48}:
MAS001437

{99982D6D-909A-451C-B0EA-6CF81B0D3B94}

  • {8A8BE3E9-621D-4576-8D55-B6DC70614F58}
  • {B00C0DC4-D2B5-4EEA-9C99-AE65FE098F48}
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Delivery port ["]
  • Maximum immersion depth [m]
  • Float switch
  • Maximum current [A]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Impeller material
  • Construction
  • Grinder
  • {8586DC09-53FA-4C09-A466-5104E5C9DD45}
  • {0FF7EA88-71A0-4C31-9DD1-9CAECFAD7EB4}

{C1BB24AE-54A9-4BCB-AEAB-87BE18753BE9}

{BC5E2A8A-8A5F-4EF7-BBE4-289FD33EBD0E} {B00C0DC4-D2B5-4EEA-9C99-AE65FE098F48}

{27057101-EAF1-4AD4-A5D1-8A6D46BB4526}

Price (VAT incl.)

PUMPA blue line PRO PSXM21.5 230V 1,5kW, drainage pump

{B00C0DC4-D2B5-4EEA-9C99-AE65FE098F48}: ZB00065127 {9B3D77AD-B721-4B54-82AB-13CD94435E19}: CEBLP {8C2EF413-6064-4000-8085-3A40403732E8}: 8596455036098

{61BA0C9D-4F27-4AB5-AA0F-987999C382E0}
>10 {D6541EE7-57DD-49C9-90E1-FC33E80E484A}
Product availability
  • central warehouse >10 {D6541EE7-57DD-49C9-90E1-FC33E80E484A}

706.06 €

Maximum flow [l/min]
500
Maximum head [m]
21
Input voltage [V]
230
Power output - P2 [kW]
1,50
Delivery port ["]
2
Maximum immersion depth [m]
25
Float switch
NO
Maximum current [A]
10
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

PUMPA blue line PRO PSXMA21.5 230V 1,5kW, drainage pump with float switch

{B00C0DC4-D2B5-4EEA-9C99-AE65FE098F48}: ZB00065126 {9B3D77AD-B721-4B54-82AB-13CD94435E19}: CEBLP {8C2EF413-6064-4000-8085-3A40403732E8}: 8596455036081

{61BA0C9D-4F27-4AB5-AA0F-987999C382E0}
>10 {D6541EE7-57DD-49C9-90E1-FC33E80E484A}
Product availability
  • central warehouse >10 {D6541EE7-57DD-49C9-90E1-FC33E80E484A}

720.58 €

Maximum flow [l/min]
500
Maximum head [m]
21
Input voltage [V]
230
Power output - P2 [kW]
1,50
Delivery port ["]
2
Maximum immersion depth [m]
25
Float switch
YES
Maximum current [A]
10
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO

{1CFDDB80-9B02-4A48-B157-55BE31F968C5}

PUMPA Blue Line PRO PSXM Application

  • Pumping of drainage water containing abrasives
  • For construction industry - mines, quarries, buildings
  • Drainage of wastewater

Characteristic Design Features of PUMPA Blue Line PRO PSXM

  • High chrome alloy impeller
  • Cast iron and stainless steel motor and pump body
  • Increased immersion depth thanks to a special high pressure resistant mechanical seal
  • PSXMA - with float switch, PSXM - without float switch

{24D9211A-CF62-4C07-A882-7F531ECBF6F9}

{1FEDA8BA-9888-4BBD-9413-816661470989}

Maximum flow [l/min]
500
Maximum head [m]
21
Input voltage [V]
230
Power output - P2 [kW]
1.50
Delivery port ["]
2
Maximum immersion depth [m]
25
Float switch
NO, YES
Maximum current [A]
10
Cable length [m]
15
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
NO
Impeller material
cast iron
Construction
submersible
Grinder
NO
