PUMPA e-line E-DRIVE PPMS2 3-30 50Hz 230V 0.88kW water plant with frequency converte

Home water pump with integrated frequency converter ensuring constant water pressure throughout the house. Thanks to the intelligent pressure boosting system, it automatically adjusts the power according to the water supply requirements. See more

Technical Specifications

Maximum flow [l/min]
83.30
Maximum head [m]
50
Power output - P2 [kW]
0.88
Suction port ["]
1

Show all Tech Specs

in stock >100 pcs

387.68 € VAT included

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Pressure booster pumps with frequency convertor
Product No.:
ZB00073416
Sale group:
CECA
EAN:
8596455042792

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Power output - P2 [kW]
  • Suction port ["]
  • Power input - P1 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Maximum particle size [mm]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Pump design
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA e-line E-DRIVE PPMS2 3-30 50Hz 230V 0.88kW water plant with frequency converte

Product No.: ZB00073416 Sale group: CECA EAN: 8596455042792

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

387.68 €

Maximum flow [l/min]
83.30
Maximum head [m]
50
Power output - P2 [kW]
0.88
Suction port ["]
1
Power input - P1 [kW]
1.15
Rated flow [l/m]
50
Rated head [m]
30
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
NO
Maximum current [A]
7.30
Maximum liquid temperature [°C]
60
Cable length [m]
1
Maximum particle size [mm]
0.20
Protection [IP]
X5
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
NO
Pump design
horizontal
Impeller material
noryl
Construction
with frequency converter
You are viewing this variant

Product description

Home water pump with integrated frequency converter ensuring constant water pressure throughout the house. Thanks to the intelligent pressure boosting system, it automatically adjusts the power according to the water supply requirements.

No more worries about fluctuating water pressure! We present to you the automatic home water pump PUMPA E-LINE E-DRIVE PPMS 2 with frequency converter, with integrated pressure vessel, pressure sensor and check valve. PPMS automatically adjusts the power according to your current water supply needs and is suitable for boosting the pressure when pumping clean water from wells or tanks. Thanks to its compact design, it fits easily into any space and thanks to the permanent magnet motor technology and intelligent power regulation, it significantly reduces energy consumption.

Use

  • pumping clean water from wells and tanks
  • for gardens and irrigation
  • for increasing the pressure when pumping water from the water supply line, from tanks incl. rainwater tanks and wells

Benefits

  • Constant water pressure: Enjoy constant water pressure in your home no matter how many taps are in use
  • Energy saving: Thanks to the permanent magnet motor and intelligent power control, it significantly reduces energy consumption.
  • Compact design: Thanks to its compactness, the water pump easily fits into any space.
  • Low noise: Enjoy comfort without disturbing noise. Our pump operates with a noise level of < 50 dB(A) during normal operation, so your home remains a peaceful and quiet place.
  • Easy to operate and safe: With integrated dry-running, overload and rotor blocking protection, along with soft start and stop of the motor, maximum safety and easy operation are ensured.
  • Versatile use: Ideal for pumping clean water from wells and tanks, watering gardens or for increasing the water pressure in the home.
  • Easy handling: Low pump weight of 7 kg.

Built-in protection functions

  • dry-running protection
  • blocked rotor protection
  • overload protection
  • overload protection
  • overvoltage protection
  • overcurrent protection
  • automatic thermal protection

Instructions

Technical Specifications

Maximum flow [l/min]
83.30
Maximum head [m]
50
Power output - P2 [kW]
0.88
Suction port ["]
1
Power input - P1 [kW]
1.15
Rated flow [l/m]
50
Rated head [m]
30
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
NO
Maximum current [A]
7.30
Maximum liquid temperature [°C]
60
Cable length [m]
1
Maximum particle size [mm]
0.20
Protection [IP]
X5
Automatic thermal protection
YES
Dry run protection
YES
Off switch
NO
Speed ​​control
YES
Capacitor
NO
Pump design
horizontal
Impeller material
noryl
Construction
with frequency converter
