PUMPA e-line JET-DRIVE 1000 50Hz 1kW pressure booster pump with frequency converter

Automatic waterworks suitable for domestic use with Pumpa tank and frequency converter. For water supply from wells, for use in recreational facilities, in gardens and for irrigation. Maximum suction capacity 8 m. See more

Technical Specifications

Maximum flow [l/min]
80
Maximum head [m]
45
Input voltage [V]
230
Power output - P2 [kW]
1

Show all Tech Specs

in stock >10 pcs

400.36 € VAT included

the price includes a recycling fee

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Pressure booster pumps with frequency convertor
Product No.:
ZB00047310
Sale group:
CECA
EAN:
8596455001003

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Suction port ["]
  • Delivery port ["]
  • Maximum suction lift [m]
  • Drinking water certificate
  • Vessel volume [l]
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Start pressure [bar]
  • Stop pressure [bar]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA e-line JET-DRIVE 1000 50Hz 1kW pressure booster pump with frequency converter

Product No.: ZB00047310 Sale group: CECA EAN: 8596455001003

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

400.36 €

Maximum flow [l/min]
80
Maximum head [m]
45
Input voltage [V]
230
Power output - P2 [kW]
1
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
NO
Vessel volume [l]
2
Maximum current [A]
6.30
Maximum liquid temperature [°C]
35
Start pressure [bar]
2
Stop pressure [bar]
2,5
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
YES
Off switch
YES
Speed ​​control
YES
Capacitor
NO
Construction
with frequency converter
You are viewing this variant

Product description

Application

  • pumping water from wells and reservoirs
  • for cottages and chalets
  • for gardens and irrigation

Benefits

  • Energy efficient - compared to traditional water supply methods, this variable frequency system is able to save from 30% to 60%.
  • Small initial investment.
  • Quiet operation, space-saving.
  • Flexible configuration, high degree of automation.
  • Long-term reliability, extended motor life - average torque and abrasion on the shaft are reduced, due to a decrease in average speed.
  • Integrated safeguarding and protection from dry running
  • Easy to install, it can be used as a replacement for domestic waterworks or traditional water tanks.
  • Direct pressurization of the water supply reduces secondary water pollution compared to traditional water supply systems.
  • The parts that come into contact with water are made of stainless steel SS304 or SS316 and are not harmful.
  • Since the system allows a so-called soft start, it prevents water hammers in the pipeline (water hammer is a pressure wave caused by a sudden change in the flow rate in the pipeline. This phenomenon is called “water hammer” because pressure waves are often accompanied by noise. Last but not least, it can do a lot of damage).

Instructions

Technical Specifications

Maximum flow [l/min]
80
Maximum head [m]
45
Input voltage [V]
230
Power output - P2 [kW]
1
Suction port ["]
1
Delivery port ["]
1
Maximum suction lift [m]
8
Drinking water certificate
NO
Vessel volume [l]
2
Maximum current [A]
6.30
Maximum liquid temperature [°C]
35
Start pressure [bar]
2
Stop pressure [bar]
2,5
Protection [IP]
54
Automatic thermal protection
YES
Dry run protection
YES
Off switch
YES
Speed ​​control
YES
Capacitor
NO
Construction
with frequency converter
