PUMPA inox line SPP-10 4-inch hydraulic part without motor

Drinking water certificate Stainless steel

previous next
PUMPA inox line SPP-10 4-inch hydraulic part without motor

PUMPA inox line SPP 4" submersible pumps are designed according to the latest technology and are made of corrosion and abrasion resistant stainless steel. The SPP series pumps meet the highest standards of energy efficiency and are suitable for the most demanding applications with their high performance, robust design and long service life. See more

Technical Specifications

Maximum flow [l/min]
40
Maximum head [m]
52 - 280
Input voltage [V]
without motor
Power output - P2 [kW]
0.37 - 2.20

Show all Tech Specs

in stock >100 pcs

from 209.52 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
MAS001371

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Drinking water certificate
  • Float switch
  • Maximum liquid temperature [°C]
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA inox line SPP-1009 4" hydraulic part without motor (0,37kW)

Product No.: ZB00059310 Sale group: CEST EAN: 8596455010661

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

209.52 €

Maximum flow [l/min]
40
Maximum head [m]
52
Input voltage [V]
without motor
Power output - P2 [kW]
0.37
Rated flow [l/m]
30
Rated head [m]
38
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1013 4" hydraulic part without motor (0,55kW)

Product No.: ZB00059311 Sale group: CEST EAN: 8596455010678

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

267.94 €

Maximum flow [l/min]
40
Maximum head [m]
76
Input voltage [V]
without motor
Power output - P2 [kW]
0.55
Rated flow [l/m]
30
Rated head [m]
53
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1018 4" hydraulic part without motor (0,75kW)

Product No.: ZB00059312 Sale group: CEST EAN: 8596455010685

in stock
>100 pcs
Product availability
  • central warehouse >100 pcs

339.57 €

Maximum flow [l/min]
40
Maximum head [m]
104
Input voltage [V]
without motor
Power output - P2 [kW]
0.75
Rated flow [l/m]
30
Rated head [m]
74
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1023 4" hydraulic part without motor (1,1kW)

Product No.: ZB00059313 Sale group: CEST EAN: 8596455010692

in stock
>50 pcs
Product availability
  • central warehouse >50 pcs

413.38 €

Maximum flow [l/min]
40
Maximum head [m]
136
Input voltage [V]
without motor
Power output - P2 [kW]
1.10
Rated flow [l/m]
30
Rated head [m]
98
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1028 4" hydraulic part without motor (1,5kW)

Product No.: ZB00059314 Sale group: CEST EAN: 8596455010708

in stock
7 pcs
Product availability
  • central warehouse 7 pcs

486.37 €

Maximum flow [l/min]
40
Maximum head [m]
166
Input voltage [V]
without motor
Power output - P2 [kW]
1.50
Rated flow [l/m]
30
Rated head [m]
121
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1033 4" hydraulic part without motor (1,5kW)

Product No.: ZB00059315 Sale group: CEST EAN: 8596455010715

in stock
>10 pcs
Product availability
  • central warehouse >10 pcs

602.87 €

Maximum flow [l/min]
40
Maximum head [m]
196
Input voltage [V]
without motor
Power output - P2 [kW]
1.50
Rated flow [l/m]
30
Rated head [m]
143
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1040 4" hydraulic part without motor (2,2kW)

Product No.: ZB00059316 Sale group: CEST EAN: 8596455010722

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

720.24 €

Maximum flow [l/min]
40
Maximum head [m]
235
Input voltage [V]
without motor
Power output - P2 [kW]
2.20
Rated flow [l/m]
30
Rated head [m]
170
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

PUMPA inox line SPP-1048 4" hydraulic part without motor (2,2kW)

Product No.: ZB00059317 Sale group: CEST EAN: 8596455010739

in stock
4 pcs
Product availability
  • central warehouse 4 pcs

913.84 €

Maximum flow [l/min]
40
Maximum head [m]
280
Input voltage [V]
without motor
Power output - P2 [kW]
2.20
Rated flow [l/m]
30
Rated head [m]
205
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal

Product description

Application

  • Drinking water supply for residential buildings from deep drilled wells
  • Utility and industrial water supply
  • Irrigation and other agricultural applications
  • Fire protection systems
  • Pressure amplification in high-rise buildings
  • Other applications

Characteristics

  • Stainless steel construction developed and manufactured to provide many years of fault-free operation
  • All metal parts are made of grade 304 stainless steel, except the shaft made of grade 431 stainless steel
  • Heavy-duty stainless steel discharge head with built-in check valve for long life and easy installation
  • Engine mounting specifications according to NEMA standard
  • High quality shaft bearings ensuring low friction and high wear resistance
  • Stainless steel impellers and diffusers for heavy loads providing optimum performance
  • Stainless steel strainer to prevent the ingress of sand and other impurities

Technical Specifications

Maximum flow [l/min]
40
Maximum head [m]
52 - 280
Input voltage [V]
without motor
Power output - P2 [kW]
0.37 - 2.20
Rated flow [l/m]
30
Rated head [m]
38 - 205
Delivery port ["]
5/4
Pump diameter ["]
4
Drinking water certificate
YES
Float switch
NO
Maximum liquid temperature [°C]
40
Maximum borehole diameter [mm]
98
Impeller material
stainless steel
Construction
centrifugal
