PUMPA inox line STP-18 4-inch submersible pump 230V 2-wire with cable

previous next
PUMPA inox line STP-18 4-inch submersible pump 230V 2-wire with cable

Pump with motor and cable of the specified length, the 230V version is started directly in the motor. The 400V set does not include a motor starter. See more

Technical Specifications

Maximum flow [l/min]
100
Maximum head [m]
59 - 93
Input voltage [V]
230
Power output - P2 [kW]
0.75 - 1.10

Show all Tech Specs

in stock 6 pcs

from 526.63 € VAT included

Choose variant

Delivery accross EU within 3-7 business days %

Brand:
PUMPA
Category:
Submersible borehole pumps
Product No.:
MAS001358

Product variants

  • Technical Specifications
  • Product No.
  • Maximum flow [l/min]
  • Maximum head [m]
  • Input voltage [V]
  • Power output - P2 [kW]
  • Rated flow [l/m]
  • Rated head [m]
  • Delivery port ["]
  • Pump diameter ["]
  • Maximum immersion depth [m]
  • Drinking water certificate
  • Float switch
  • Maximum current [A]
  • Maximum liquid temperature [°C]
  • Cable length [m]
  • Protection [IP]
  • Automatic thermal protection
  • Dry run protection
  • Off switch
  • Speed ​​control
  • Capacitor
  • Maximum borehole diameter [mm]
  • Impeller material
  • Construction
  • Availability
  • Price

next

Variant Product No.

Availability

Price (VAT incl.)

PUMPA inox line STP-1809 4" 0,75kW 230V 2-wire motor, submersible pump, cable 30m

Product No.: ZB00060250 Sale group: CEST EAN: 8596455018124

available in 5 working days
>10 pcs
Product availability
  • central warehouse 0 pcs
  • available within 5 working days >10 pcs

526.63 €

Maximum flow [l/min]
100
Maximum head [m]
59
Input voltage [V]
230
Power output - P2 [kW]
0,75
Rated flow [l/m]
60
Rated head [m]
43
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
80
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6,50
Maximum liquid temperature [°C]
35
Cable length [m]
25
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

PUMP INOX LINE STP-1814 4" 1,1kW 230V 2-wire motor, submersible pump, cable 40m

Product No.: ZB00072976 Sale group: CEST EAN: 8596455042396

in stock
6 pcs
Product availability
  • central warehouse 6 pcs
  • available within 5 working days >10 pcs

615.51 €

Maximum flow [l/min]
100
Maximum head [m]
93
Input voltage [V]
230
Power output - P2 [kW]
1,10
Rated flow [l/m]
60
Rated head [m]
68
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
80
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
8,50
Maximum liquid temperature [°C]
35
Cable length [m]
40
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
this variant suits your choice

Product description

Application

  • Drinking water supply for residential buildings from deep drilled wells
  • Utility and industrial water supply
  • Irrigation and other agricultural applications
  • Fire protection systems
  • Pressure amplification in high-rise buildings
  • Other applications

Characteristics

  • Stainless steel construction developed and manufactured to provide many years of fault-free operation
  • All metal parts are made of grade 304 stainless steel, except the shaft made of grade 431 stainless steel
  • Heavy-duty stainless steel discharge head with built-in check valve for long life and easy installation
  • Engine mounting specifications according to NEMA standard
  • High quality shaft bearings ensuring low friction and high wear resistance
  • Floating impellers are made with the addition of NorylR material for perfect sand processing.
  • Stainless steel strainer to prevent the ingress of sand and other impurities

Instructions

Technical Specifications

Maximum flow [l/min]
100
Maximum head [m]
59 - 93
Input voltage [V]
230
Power output - P2 [kW]
0.75 - 1.10
Rated flow [l/m]
60
Rated head [m]
43 - 68
Delivery port ["]
5/4
Pump diameter ["]
4
Maximum immersion depth [m]
80
Drinking water certificate
NO
Float switch
NO
Maximum current [A]
6.50 - 8.50
Maximum liquid temperature [°C]
35
Cable length [m]
25 - 40
Protection [IP]
68
Automatic thermal protection
YES
Dry run protection
NO
Off switch
NO
Speed ​​control
NO
Capacitor
integrated
Maximum borehole diameter [mm]
98
Impeller material
noryl
Construction
centrifugal
