WILO STRATOS MAXO-Z smart glandless threaded circulator

Your benefits

• Intuitive operation thanks to guided settings with the Setup Guide and in combination with the new display and control knob with "green button technology".
• Maximum drinking water hygiene and energy efficiency thanks to the new innovative and intelligent regulation function T-const.
• Optimum hygiene support thanks to temperature disinfection identification.
• The latest communication interface (e.g. Bluetooth) for connecting to mobile end devices and directly connecting the pumps to the network via the Wilo Net network for controlling several pumps at the same time.
• Maximum comfort when installing electrical systems thanks to the clear and generously designed space for terminals and the optimized Wilo-Connector.

The power of intelligence, a unique quality

Wilo-Stratos MAXO-Z developed specifically for use with potable water combines the innovative properties of Wilo-Stratos MAXO with a stainless steel housing. Long-lasting, hygienic material sets them apart from other hot drinking water circulation pumps on the market.

Use

Drinking water circulation systems of all designs, hot water heating of all systems, air conditioning equipment, closed cooling circuits, industrial circulation equipment

Heating

• Radiators
• Floor heating
• Ceiling heating
• Air heaters
• Hydraulic branch
• Heat Exchanger

Cooling

• Ceiling cooling
• Floor cooling
• Air conditioning equipment
• Hydraulic branch
• Heat Exchanger

Combination of heating and cooling

• Automatic switching

Advantages

Automatic functions

• Performance adaptation optimized as needed for energy-efficient operation depending on the operating mode
• Recognition of attenuation mode
• Shutdown when zero flow is detected (No-Flow Stop)
• A soft start
• Automatic routines to remove errors (e.g. unlock function)
  Heating/cooling switching
  Full motor protection with integrated start electronics

Delivery contents

• Pump
• Optimized Wilo-Connector
• 2x M16 x 1.5 cable gland
• Washers for flange screws (for connections with nominal diameter DN 32 - DN 65)
• Including a seal in the case of a threaded connection
• Heat insulation
• Installation and operating instructions

Materials

• Stainless steel pump cover
• Thermal insulation: polypropylene
• Impeller: Plastic
• Shaft: Stainless steel
• Bearing: Carbon

Description/construction

• Wet running Smart circulation pump with EC motor and integrated electrical power adjustment
• Green button technology and graphic display
• Motor protection with start electronics
• Plug for expanding functions with an optional CIF module for building automation
• Impeller with three-dimensional curved blades and carbon fiber composite plastic separation tube
